HARDWARE INDEX
| Size | 60mm length*40mm width*4.2mm height |
| Connection method | Board to Board Connector |
| CPU | ROCKCHIP RK3566 quad core A55 |
| GPU | Mali G52 |
| RAM | DDR4 standard 2GB optional 4G |
| Memory | EMMC 5.1 standard 8GB optional 16GB/32G/64G/128G |
| Power management | RK809-5 |
| lithium battery | Charge detection |
| Operating Voltage | 3.3V 3A or more |
| support system | Andriod11/ubuntu/Linux4.19+QT5.12 |
| Operating temperature | -10 to +75 degrees |
| Life span | Continuous operating life is more than 5 years |
COMMONINTERFACE
| HDMI | HDMI high-definition output support 1080P display |
| EDP | Support 4Lane eDP up to 1080P |
| LVDS | Support single channel LVDS display output up to 1280x800 |
| MIPI DSI | Support 8Lane, up to 2K |
| RGB | Support RGB888 24-bit number interface |
| DVP camera | Support 16 bit DVP interface camera input |
| MIPI CSI | Two-way CSI supports up to 800W |
| I2S | Two I2S channels, one channel 8 channels / one channel 2 channels |
| PCIE | 1 PCIE 3.0 x2, and 1 PCIE2.0 x1 |
| SATA | 1 way SATA3.0, another way SATA2.0 |
| USB2.0 | Four independent USB2.0, one of which is OTG |
| USB3.0 | Two-way USB 3.0 interface |
| Ethernet | 2 way RGMII Ethernet interface |
| UART | 10 serial ports |
| SPI | 3 way SPI |
| I2C | 4-channel I2C |
| PWM | 15-channel PWM |
| SDIO | 3 SDIO interfaces, one is TF card, the other is WIFI |
| ADC | 8-channel analog ADC input interface |
| GPIO | Reusable GPIO up to 130 |
| Voice input | Two-way analog voice input |
| Voice output | One way is headphone output, the other way is mono speaker output power 0.6W |
| Upgrade | Support USB/TF card local upgrade |
CORRENT PARAMETER TABLE
| Item | The smallest | Typical | maximum | |
| Power parameters | Voltage | 3.3V | 3.3V | 3.4V |
| Ripple | 50mV | |||
| 3V RTC power consumption | 0.3uA | 0.9uA | 1.2uA | |
Mainboard current test (Other peripherals are not connected) | Turn-on current | 273mA | 345mA | 465mA |
| Desktop quiescent current | 325mA | |||
| surroundings | Relative humidity | -- | 65% | 75% |
| Working temperature | -10℃ | -- | 75℃ | |
| Storage temperature | -30℃ | -0℃ | 100℃ | |
