Samsung RP4412 Core board

深圳市荣品电子科技有限公司

联系方式: 0755-235747363

地址: 广东省深圳市宝安区西乡街道华丰国际机器人产业园二期A座三楼(固戍地铁C出口)

Product description

1.MAIN HARDWARE INDICATORS

SIZE	60*55mm
HEIGHT	26mm
TECHNOLOGY	Technology of High Strength HDI Half-Hole Plate with 8 Layers
CPU	Exynos4412，Quad core Cortex-A9，Main frequency 1.4GHz-1.6GHz
PMU	ACT8848QM Dynamic Power Management
MEMORY	2GB Dual Channel DDR3
STORAGE	4GB EMMC4.5（Batch Options 16GB）
HSIC	USB3503A
WORKING VOLTAGE	5V（Recommended use of standard 5V/3A power cord）
PIN EXPANSION	Lead-out foot up to 220 PIN, to meet the user's various practical expansion needs
OPERATING TEMPERATURE	Form -10℃ to 75℃
SUPPORT SYSTEM	Android4.4（Recommend）、Ubuntu、Linux+QT2.2

⒉PRODUCT PICTURES

（Positive）

⒊PCB DIMENSION MAP

（Positive）
